# Interpreting the cluster graph
{% hint style="info" %}
This is an older version of the document. To view the most recent version of the document, click [here](https://docs.opsmx.com/products/data-and-intelligence-module-autopilot/autopilot/log-analysis/interpreting-the-cluster-graph).
{% endhint %}
The summary of the log events for risk analysis is represented in a bubble graph.
The x-axis represents the sequence number of events and the y-axis is the logical representation of the number of times the events are repeated within the cluster.
Mouse over the bubbles to display repetition count of event along with the starting event string.
### **Impact on score**
Impact on score calculation for a cluster:
W = weight assigned for the cluster topic at a given sensitivity level
L1 = No of unique clusters in V1
L12 = No of unique clusters in V1V2
C = Total number of all dark red, red and yellow clusters in both V2 and V1V2
N=(L1\*10) / (L1+L12)
Impact on score for a cluster= (W/(L1+L12))+(N/C)+ Score reduced based on number of repetitions
{% hint style="info" %}
Score reduction is calculated for only non green clusters in V2 and V1V2
{% endhint %}
